SoNode Class Reference
[Nodes]
Abstract base class for all database nodes. More...
#include <Inventor/nodes/SoNode.h>
Public Member Functions | |
| virtual SoType | getTypeId () const |
| virtual void | setOverride (const SbBool state) |
| virtual SbBool | isOverride () const |
| virtual SoNode * | copy (SbBool copyConnections=FALSE) const |
| virtual SbBool | affectsState () const |
| virtual void | touch () |
Static Public Member Functions | |
| static SoType | getClassTypeId () |
| static SoNode * | getByName (const SbName &name) |
| static int | getByName (const SbName &name, SoNodeList &list) |
Friends | |
| class | SoTraversalPassImpl |
| class | SoLdmValuationAction |
| class | SoPath |
| class | SoLightPath |
| class | SoAction |
| class | StringConcatCallback |
| class | SoChildList |
| class | SoCacheElement |
| class | inventor::impl::SoCachedGroupImpl |
| class | inventor::node::SoConstNode |
Detailed Description
Abstract base class for all database nodes.
This is the abstract base class from which all scene graph node classes are derived.
FILE FORMAT/DEFAULT
- This is an abstract class. See the reference page of a derived class for the format and default values.
ACTION BEHAVIOR
- SoSearchAction
If the node, type, or name matches the search criteria, returns a path to the node.
SoWriteAction
Writes the contents of the node to the current SoOutput.
SEE ALSO
- See related examples:
Member Function Documentation
| virtual SbBool SoNode::affectsState | ( | ) | const [virtual] |
Returns TRUE if a node has an effect on the state during traversal.
The default method returns TRUE. Node classes (such as SoSeparator) that isolate their effects from the rest of the graph override this method to return FALSE.
Reimplemented in SoInteractionKit, SoNodeKitListPart, SoSceneKit, SoSeparatorKit, SoArray, SoInteractiveSwitch, SoMultipleCopy, SoMultiSwitch, SoShape, PoBase, and SoOrthoSlice.
Creates and returns an exact copy of the node.
If the node is a group, it copies the children as well. If copyConnections is TRUE (it is FALSE by default), any connections to (but not from) fields of the node are copied, as well. Note that multiple references to a node under the node to be copied will result in multiple references to the copy of that node.
Reimplemented in SoClipPlaneManip, and PoBase.
| static int SoNode::getByName | ( | const SbName & | name, | |
| SoNodeList & | list | |||
| ) | [static] |
A node's name can be set using SoBase::setName().
This method allows nodes to be looked up by net name. It returns the number of nodes with the given net name, and adds to list those nodes.
A node's name can be set using SoBase::setName().
This method allows nodes to be looked up by name. It returns the last node given the specified name.
| static SoType SoNode::getClassTypeId | ( | ) | [static] |
Returns the type identifier for this class.
Reimplemented from SoFieldContainer.
Reimplemented in SoCenterballDragger, SoDirectionalLightDragger, SoDragger, SoDragPointDragger, SoEllipsoidDragger, SoHandleBoxDragger, SoJackDragger, SoPointLightDragger, SoRotateCylindricalDragger, SoRotateDiscDragger, SoRotateSphericalDragger, SoScale1Dragger, SoScale2Dragger, SoScale2UniformDragger, SoScaleUniformDragger, SoSpotLightDragger, SoTabBoxDragger, SoTabPlaneDragger, SoTrackballDragger, SoTransformBoxDragger, SoTransformerDragger, SoTranslate1Dragger, SoTranslate2Dragger, SoEllipseScreenDrawer, SoLassoScreenDrawer, SoPolygonScreenDrawer, SoPolyLineScreenDrawer, SoRectangleScreenDrawer, SoScreenDrawer, SoGeoCoordinate, SoGeoElevationGrid, SoGeoLocation, SoGeoLOD, SoGeoOrigin, SoGeoRender, PoBaseView, PoSceneView, PoView, SoCenterballManip, SoClipPlaneManip, SoDirectionalLightManip, SoHandleBoxManip, SoJackManip, SoPointLightManip, SoSpotLightManip, SoTabBoxManip, SoTrackballManip, SoTransformBoxManip, SoTransformerManip, SoTransformManip, SoAppearanceKit, SoBaseKit, SoCameraKit, SoInteractionKit, SoLightKit, SoNodeKitListPart, SoSceneKit, SoSeparatorKit, SoShapeKit, SoWrapperKit, SoAlgebraicCone, SoAlgebraicCylinder, SoAlgebraicShape, SoAlgebraicSphere, SoAlphaPolicy, SoAnnotation, SoAnnoText3, SoAnnoText3Property, SoAntiSquish, SoArray, SoAsciiText, SoBackground, SoBaseColor, SoBaseExtrusion, SoBBox, SoBevelProperty, SoBillboard, SoBlinker, SoBufferedShape, SoCallback, SoCamera, SoCircularExtrusion, SoClipPlane, SoColorIndex, SoColorMap, SoComplexity, SoCone, SoCoordinate3, SoCoordinate4, SoCSGShape, SoCube, SoCylinder, SoDepthBuffer, SoDepthOffset, SoDirectionalLight, SoDrawStyle, SoEdgeFlag, SoEnvironment, SoEventCallback, SoExtrusion, SoExtSelection, SoExtTexture2, SoFaceSet, SoFile, SoFont, SoFontStyle, SoFragmentShader, SoFullSceneAntialiasing, SoGeometryShader, SoGeoProjection, SoGLCallback, SoGradientBackground, SoGroup, SoImage, SoImageBackground, SoIndexedFaceSet, SoIndexedLineSet, SoIndexedMarkerSet, SoIndexedNurbsCurve, SoIndexedNurbsSurface, SoIndexedPointSet, SoIndexedQuadMesh, SoIndexedShape, SoIndexedTexture2, SoIndexedTriangleFanSet, SoIndexedTriangleSet, SoIndexedTriangleStripSet, SoInfo, SoInstanceParameter, SoInteractiveComplexity, SoInteractiveSwitch, SoLabel, SoLevelOfDetail, SoLevelOfSimplification, SoLight, SoLightModel, SoLinearProfile, SoLineSet, SoLocateHighlight, SoLOD, SoMarker, SoMarkerSet, SoMaterial, SoMaterialBinding, SoMatrixTransform, SoMultiPathSwitch, SoMultipleCopy, SoMultipleInstance, SoMultipleInstanceBase, SoMultiSwitch, SoNonIndexedShape, SoNormal, SoNormalBinding, SoNurbsBoundary, SoNurbsCurve, SoNurbsGroup, SoNurbsProfile, SoNurbsProperty, SoNurbsSurface, SoOrthographicCamera, SoPackedColor, SoPathSwitch, SoPattern, SoPendulum, SoPerspectiveCamera, SoPickStyle, SoPointLight, SoPointSet, SoPolygonOffset, SoProfile, SoProfileCoordinate2, SoProfileCoordinate3, SoProjection, SoQuadMesh, SoRenderToTarget, SoRenderToTextureProperty, SoResetTransform, SoRotation, SoRotationXYZ, SoRotor, SoScale, SoSelection, SoSeparator, SoShaderObject, SoShaderParameter, SoUniformShaderParameter, SoShaderParameter1f, SoShaderParameter1i, SoShaderParameter2f, SoShaderParameter2i, SoShaderParameter3f, SoShaderParameter3i, SoShaderParameter4f, SoShaderParameter4i, SoShaderParameterArray1f, SoShaderParameterArray1i, SoShaderParameterArray2f, SoShaderParameterArray2i, SoShaderParameterArray3f, SoShaderParameterArray3i, SoShaderParameterArray4f, SoShaderParameterArray4i, SoShaderParameterMatrix, SoShaderParameterMatrix3, SoShaderParameterMatrixArray, SoShaderStateMatrixParameter, SoShaderParameterStruct, SoVertexShaderParameter, SoVertexShaderParameter1f, SoVertexShaderParameter1s, SoVertexShaderParameter2f, SoVertexShaderParameter2s, SoVertexShaderParameter3f, SoVertexShaderParameter3s, SoVertexShaderParameter4f, SoVertexShaderParameter4i, SoVertexShaderParameter4s, SoVertexShaderParameter4b, SoVertexShaderParameter4ui, SoVertexShaderParameter4us, SoVertexShaderParameter4ub, SoVertexShaderParameterMatrix, SoVertexShaderParameterBufferObject, SoShaderParameterBufferObject, SoShaderProgram, SoShadowGroup, SoShadowStyle, SoShape, SoShapeHints, SoShuttle, SoSphere, SoSpotLight, SoStereoCamera, SoSurroundScale, SoSwitch, SoTessellationControlShader, SoTessellationEvaluationShader, SoText2, SoText3, SoTextProperty, SoTexture, SoTexture2, SoTexture2Transform, SoTexture3, SoTexture3Transform, SoTextureCombiner, SoTextureCoordinate2, SoTextureCoordinate3, SoTextureCoordinateBinding, SoTextureCoordinateDefault, SoTextureCoordinateEnvironment, SoTextureCoordinateFunction, SoTextureCoordinateNormalMap, SoTextureCoordinateObject, SoTextureCoordinatePlane, SoTextureCoordinateReflectionMap, SoTextureCubeMap, SoTextureMatrix, SoTextureUnit, SoTransform, SoTransformation, SoTransformProjection, SoTransformSeparator, SoTranslation, SoTriangleSet, SoTriangleStripSet, SoUnits, SoVertexAttribFeedback, SoVertexFlag, SoVertexProperty, SoVertexShader, SoVertexShape, SoViewport, SoViewportClipping, SoWWWAnchor, SoWWWInline, SoROIManip, SoDataCompositor, SoDataRange, SoDataSet, SoDataSetId, SoGeometryPriority, SoHardwareQuery, SoLdmShape, SoMultiDataSeparator, SoROI, SoTransferFunction, DicomInfo, Gnomon, Magnifier, ObliqueSliceBorder, OrthoSliceBorder, PlaneBoxIntersection, PlaneGeometryIntersection, Ruler, SceneView, SliceOrientationMarkers, SliceScaleBar, TextBox, ViewManager, Po3DdataMaster, PoBaseStreamLine, PoCellEdges, PoCellFacets, PoCellIndices, PoCellShape, PoMesh, PoMesh2D, PoMesh2DVec, PoMesh3D, PoMesh3DVec, PoMesh3DVecCrossSection, PoMesh3DVecGridCrossSection, PoMeshContouring, PoMeshCrossContour, PoMeshCrossSection, PoMeshFilled, PoMeshLevelSurf, PoMeshLimit, PoMeshLines, PoMeshProbePoint, PoMeshSides, PoMeshSkeleton, PoMeshSkin, PoStreamLine, PoStreamLineMotion, PoStreamParticleMotion, PoStreamPointMotion, PoStreamSphereMotion, PoStreamSurface, PoStreamTadpoleMotion, PoAngularAxis, PoArrow, PoArrow3, PoAutoCubeAxis, PoAutoValueLegend, PoAxis, PoBar, PoBase, PoBaseAxis, PoBiErrorPointField, PoCartesianAxis, PoChart, PoCircle, PoCircle3, PoCircle3CenterRadius, PoCircle3ThreePoints, PoCircleArc, PoCircleArc3, PoCircleArc3CtrPtAngle, PoCircleArc3CtrTwoPts, PoCircleArc3ThreePts, PoCircleArcCtrPtAngle, PoCircleArcCtrRadTwoAngle, PoCircleArcCtrTwoPts, PoCircleArcThreePts, PoCircleCenterRadius, PoCircleThreePoints, PoConicBar, PoCoordinateSystemAxis, PoCurve, PoCurve3, PoCurveFilling, PoCurveLine, PoCylindricalBar, PoErrorCurve, PoErrorPointField, PoGenAxis, PoGeneralizedBar, PoGeneralizedScatter, PoGraphMaster, PoGroup2Axis, PoGroup3Axis3, PoGroup4Axis, PoGroup6Axis3, PoHighLowClose, PoHistogram, PoItemLegend, PoLabel, PoLabelField, PoLegend, PoLinearAxis, PoLinearBar, PoLinearValueLegend, PoLogAxis, PoMultipleHistogram, PoNonLinearValueLegend1, PoNonLinearValueLegend2, PoNonLinearValueLegend3, PoParallelogram, PoParallelogram3, PoPieChart, PoPieChart2D, PoPieChart3D, PoPieChartRep, PoPointsFieldBars, PoPolarAxis, PoPolarLinAxis, PoPolarLogAxis, PoProfileBar, PoRectangle, PoRibbon, PoScatter, PoSingleHistogram, PoTimeAxis, PoTube, PoValuedMarkerField, PoValueLegend, PoBevelEdge, PoCartesianGrid2D, PoCartesianGrid3D, PoCellFilter, PoCircularProfile, PoCoordinateListFilter, PoDataMapping, PoDateFormatMapping, PoDomain, PoEllipticProfile, PoHexahedronMesh3D, PoIndexedMesh2D, PoIndexedMesh3D, PoIndexListFilter, PoIntervalCellFilter, PoIrregularMesh1D, PoIsovaluesList, PoLabelHints, PoLinearDataMapping, PoMesh1DFilter, PoMesh1DHints, PoMeshProperty, PoMiscTextAttr, PoNode, PoNonLinearDataMapping, PoNonLinearDataMapping2, PoNumericDisplayFormat, PoParalCartesianGrid2D, PoParalCartesianGrid3D, PoPeriodFilter, PoPeriodIndexFilter, PoPolarGrid2D, PoProfile, PoProfileCoordinate2, PoQuadrangleMesh2D, PoRegularCartesianGrid2D, PoRegularCartesianGrid3D, PoRegularMesh1D, PoSquareProfile, PoTetrahedronMesh3D, PoTriangleMesh2D, MoActionNode, MoCellFilter, MoColorMapping, MoCombineColorMapping, MoCustomColorMapping, MoDataBinding, MoDrawStyle, MoLegend, MoLevelColorMapping, MoLinearColorMapping, MoMaterial, MoMesh, MoMeshAnnotatedIsoline, MoMeshBaseRepresentation, MoMeshCellShape, MoMeshClipLine, MoMeshClipPoint, MoMeshCylinderSlice, MoMeshElevatedPlaneSlice, MoMeshFenceSlice, MoMeshGridPlaneSlice, MoMeshInterpolatedLogicalSlice, MoMeshIsoline, MoMeshIsosurface, MoMeshLine, MoMeshLineRepresentation, MoMeshLogicalSlice, MoMeshOutline, MoMeshPlaneSlice, MoMeshPointProbe, MoMeshRepresentation, MoMeshSkin, MoMeshSlab, MoMeshSphereSlice, MoMeshStreamline, MoMeshSurface, MoMeshSurfaceRepresentation, MoMeshVector, MoPredefinedColorMapping, MoScalarSet, MoScalarSetI, MoScalarSetIj, MoScalarSetIjk, MoStringSet, MoTessellator, MoVec3SetI, MoVec3SetIj, MoVec3SetIjk, SoRemoteVizClient, SoOrthoSliceDragger, SoFenceSlice, SoHeightFieldGeometry, SoHeightFieldProperty, SoHeightFieldPropertyMask, SoHeightFieldRender, SoObliqueSlice, SoOffscreenVolumeRender, SoOrthoSlice, SoSlice, SoUniformGridClipping, SoUniformGridProjectionClipping, SoVolumeBufferedShape, SoVolumeClippingGroup, SoVolumeData, SoVolumeDataDrawStyle, SoVolumeFaceSet, SoVolumeGroup, SoVolumeIndexedFaceSet, SoVolumeIndexedTriangleStripSet, SoVolumeIsosurface, SoVolumeMask, SoVolumeMaskGroup, SoVolumeRender, SoVolumeRenderingPhysicalQuality, SoVolumeRenderingQuality, SoVolumeShader, SoVolumeShape, SoVolumeSkin, SoVolumeTransform, SoVolumeTriangleStripSet, MedicalCPUDataCompositor, SoOffscreenVolumeRenderCustom, and SoTransferFunction2D.
| virtual SoType SoNode::getTypeId | ( | ) | const [virtual] |
Returns the type identifier for this specific instance.
Implements SoTypedObject.
Reimplemented in SoCenterballDragger, SoDirectionalLightDragger, SoDragger, SoDragPointDragger, SoEllipsoidDragger, SoHandleBoxDragger, SoJackDragger, SoPointLightDragger, SoRotateCylindricalDragger, SoRotateDiscDragger, SoRotateSphericalDragger, SoScale1Dragger, SoScale2Dragger, SoScale2UniformDragger, SoScaleUniformDragger, SoSpotLightDragger, SoTabBoxDragger, SoTabPlaneDragger, SoTrackballDragger, SoTransformBoxDragger, SoTransformerDragger, SoTranslate1Dragger, SoTranslate2Dragger, SoEllipseScreenDrawer, SoLassoScreenDrawer, SoPolygonScreenDrawer, SoPolyLineScreenDrawer, SoRectangleScreenDrawer, SoScreenDrawer, SoGeoCoordinate, SoGeoElevationGrid, SoGeoLocation, SoGeoLOD, SoGeoOrigin, SoGeoRender, PoBaseView, PoSceneView, PoView, SoCenterballManip, SoClipPlaneManip, SoDirectionalLightManip, SoHandleBoxManip, SoJackManip, SoPointLightManip, SoSpotLightManip, SoTabBoxManip, SoTrackballManip, SoTransformBoxManip, SoTransformerManip, SoTransformManip, SoAppearanceKit, SoBaseKit, SoCameraKit, SoInteractionKit, SoLightKit, SoNodeKitListPart, SoSceneKit, SoSeparatorKit, SoShapeKit, SoWrapperKit, SoAlgebraicCone, SoAlgebraicCylinder, SoAlgebraicShape, SoAlgebraicSphere, SoAlphaPolicy, SoAnnotation, SoAnnoText3, SoAnnoText3Property, SoAntiSquish, SoArray, SoAsciiText, SoBackground, SoBaseColor, SoBaseExtrusion, SoBBox, SoBevelProperty, SoBillboard, SoBlinker, SoBufferedShape, SoCallback, SoCamera, SoCircularExtrusion, SoClipPlane, SoColorIndex, SoColorMap, SoComplexity, SoCone, SoCoordinate3, SoCoordinate4, SoCSGShape, SoCube, SoCylinder, SoDepthBuffer, SoDepthOffset, SoDirectionalLight, SoDrawStyle, SoEdgeFlag, SoEnvironment, SoEventCallback, SoExtrusion, SoExtSelection, SoExtTexture2, SoFaceSet, SoFile, SoFont, SoFontStyle, SoFragmentShader, SoFullSceneAntialiasing, SoGeometryShader, SoGeoProjection, SoGLCallback, SoGradientBackground, SoGroup, SoImage, SoImageBackground, SoIndexedFaceSet, SoIndexedLineSet, SoIndexedMarkerSet, SoIndexedNurbsCurve, SoIndexedNurbsSurface, SoIndexedPointSet, SoIndexedQuadMesh, SoIndexedShape, SoIndexedTexture2, SoIndexedTriangleFanSet, SoIndexedTriangleSet, SoIndexedTriangleStripSet, SoInfo, SoInstanceParameter, SoInteractiveComplexity, SoInteractiveSwitch, SoLabel, SoLevelOfDetail, SoLevelOfSimplification, SoLight, SoLightModel, SoLinearProfile, SoLineSet, SoLocateHighlight, SoLOD, SoMarker, SoMarkerSet, SoMaterial, SoMaterialBinding, SoMatrixTransform, SoMultiPathSwitch, SoMultipleCopy, SoMultipleInstance, SoMultipleInstanceBase, SoMultiSwitch, SoNonIndexedShape, SoNormal, SoNormalBinding, SoNurbsBoundary, SoNurbsCurve, SoNurbsGroup, SoNurbsProfile, SoNurbsProperty, SoNurbsSurface, SoOrthographicCamera, SoPackedColor, SoPathSwitch, SoPattern, SoPendulum, SoPerspectiveCamera, SoPickStyle, SoPointLight, SoPointSet, SoPolygonOffset, SoProfile, SoProfileCoordinate2, SoProfileCoordinate3, SoProjection, SoQuadMesh, SoRenderToTarget, SoRenderToTextureProperty, SoResetTransform, SoRotation, SoRotationXYZ, SoRotor, SoScale, SoSelection, SoSeparator, SoShaderObject, SoShaderParameter, SoUniformShaderParameter, SoShaderParameter1f, SoShaderParameter1i, SoShaderParameter2f, SoShaderParameter2i, SoShaderParameter3f, SoShaderParameter3i, SoShaderParameter4f, SoShaderParameter4i, SoShaderParameterArray1f, SoShaderParameterArray1i, SoShaderParameterArray2f, SoShaderParameterArray2i, SoShaderParameterArray3f, SoShaderParameterArray3i, SoShaderParameterArray4f, SoShaderParameterArray4i, SoShaderParameterMatrix, SoShaderParameterMatrix3, SoShaderParameterMatrixArray, SoShaderStateMatrixParameter, SoShaderParameterStruct, SoVertexShaderParameter, SoVertexShaderParameter1f, SoVertexShaderParameter1s, SoVertexShaderParameter2f, SoVertexShaderParameter2s, SoVertexShaderParameter3f, SoVertexShaderParameter3s, SoVertexShaderParameter4f, SoVertexShaderParameter4i, SoVertexShaderParameter4s, SoVertexShaderParameter4b, SoVertexShaderParameter4ui, SoVertexShaderParameter4us, SoVertexShaderParameter4ub, SoVertexShaderParameterMatrix, SoVertexShaderParameterBufferObject, SoShaderParameterBufferObject, SoShaderProgram, SoShadowGroup, SoShadowStyle, SoShape, SoShapeHints, SoShuttle, SoSphere, SoSpotLight, SoStereoCamera, SoSurroundScale, SoSwitch, SoTessellationControlShader, SoTessellationEvaluationShader, SoText2, SoText3, SoTextProperty, SoTexture, SoTexture2, SoTexture2Transform, SoTexture3, SoTexture3Transform, SoTextureCombiner, SoTextureCoordinate2, SoTextureCoordinate3, SoTextureCoordinateBinding, SoTextureCoordinateDefault, SoTextureCoordinateEnvironment, SoTextureCoordinateFunction, SoTextureCoordinateNormalMap, SoTextureCoordinateObject, SoTextureCoordinatePlane, SoTextureCoordinateReflectionMap, SoTextureCubeMap, SoTextureMatrix, SoTextureUnit, SoTransform, SoTransformation, SoTransformProjection, SoTransformSeparator, SoTranslation, SoTriangleSet, SoTriangleStripSet, SoUnits, SoVertexAttribFeedback, SoVertexFlag, SoVertexProperty, SoVertexShader, SoVertexShape, SoViewport, SoViewportClipping, SoWWWAnchor, SoWWWInline, SoROIManip, SoDataCompositor, SoDataRange, SoDataSet, SoDataSetId, SoGeometryPriority, SoHardwareQuery, SoLdmShape, SoMultiDataSeparator, SoROI, SoTransferFunction, DicomInfo, Gnomon, Magnifier, ObliqueSliceBorder, OrthoSliceBorder, PlaneBoxIntersection, PlaneGeometryIntersection, Ruler, SceneView, SliceOrientationMarkers, SliceScaleBar, TextBox, ViewManager, Po3DdataMaster, PoBaseStreamLine, PoCellEdges, PoCellFacets, PoCellIndices, PoCellShape, PoMesh, PoMesh2D, PoMesh2DVec, PoMesh3D, PoMesh3DVec, PoMesh3DVecCrossSection, PoMesh3DVecGridCrossSection, PoMeshContouring, PoMeshCrossContour, PoMeshCrossSection, PoMeshFilled, PoMeshLevelSurf, PoMeshLimit, PoMeshLines, PoMeshProbePoint, PoMeshSides, PoMeshSkeleton, PoMeshSkin, PoStreamLine, PoStreamLineMotion, PoStreamParticleMotion, PoStreamPointMotion, PoStreamSphereMotion, PoStreamSurface, PoStreamTadpoleMotion, PoAngularAxis, PoArrow, PoArrow3, PoAutoCubeAxis, PoAutoValueLegend, PoAxis, PoBar, PoBase, PoBaseAxis, PoBiErrorPointField, PoCartesianAxis, PoChart, PoCircle, PoCircle3, PoCircle3CenterRadius, PoCircle3ThreePoints, PoCircleArc, PoCircleArc3, PoCircleArc3CtrPtAngle, PoCircleArc3CtrTwoPts, PoCircleArc3ThreePts, PoCircleArcCtrPtAngle, PoCircleArcCtrRadTwoAngle, PoCircleArcCtrTwoPts, PoCircleArcThreePts, PoCircleCenterRadius, PoCircleThreePoints, PoConicBar, PoCoordinateSystemAxis, PoCurve, PoCurve3, PoCurveFilling, PoCurveLine, PoCylindricalBar, PoErrorCurve, PoErrorPointField, PoGenAxis, PoGeneralizedBar, PoGeneralizedScatter, PoGraphMaster, PoGroup2Axis, PoGroup3Axis3, PoGroup4Axis, PoGroup6Axis3, PoHighLowClose, PoHistogram, PoItemLegend, PoLabel, PoLabelField, PoLegend, PoLinearAxis, PoLinearBar, PoLinearValueLegend, PoLogAxis, PoMultipleHistogram, PoNonLinearValueLegend1, PoNonLinearValueLegend2, PoNonLinearValueLegend3, PoParallelogram, PoParallelogram3, PoPieChart, PoPieChart2D, PoPieChart3D, PoPieChartRep, PoPointsFieldBars, PoPolarAxis, PoPolarLinAxis, PoPolarLogAxis, PoProfileBar, PoRectangle, PoRibbon, PoScatter, PoSingleHistogram, PoTimeAxis, PoTube, PoValuedMarkerField, PoValueLegend, PoBevelEdge, PoCartesianGrid2D, PoCartesianGrid3D, PoCellFilter, PoCircularProfile, PoCoordinateListFilter, PoDataMapping, PoDateFormatMapping, PoDomain, PoEllipticProfile, PoHexahedronMesh3D, PoIndexedMesh2D, PoIndexedMesh3D, PoIndexListFilter, PoIntervalCellFilter, PoIrregularMesh1D, PoIsovaluesList, PoLabelHints, PoLinearDataMapping, PoMesh1DFilter, PoMesh1DHints, PoMeshProperty, PoMiscTextAttr, PoNode, PoNonLinearDataMapping, PoNonLinearDataMapping2, PoNumericDisplayFormat, PoParalCartesianGrid2D, PoParalCartesianGrid3D, PoPeriodFilter, PoPeriodIndexFilter, PoPolarGrid2D, PoProfile, PoProfileCoordinate2, PoQuadrangleMesh2D, PoRegularCartesianGrid2D, PoRegularCartesianGrid3D, PoRegularMesh1D, PoSquareProfile, PoTetrahedronMesh3D, PoTriangleMesh2D, MoActionNode, MoCellFilter, MoColorMapping, MoCombineColorMapping, MoCustomColorMapping, MoDataBinding, MoDrawStyle, MoLegend, MoLevelColorMapping, MoLinearColorMapping, MoMaterial, MoMesh, MoMeshAnnotatedIsoline, MoMeshBaseRepresentation, MoMeshCellShape, MoMeshClipLine, MoMeshClipPoint, MoMeshCylinderSlice, MoMeshElevatedPlaneSlice, MoMeshFenceSlice, MoMeshGridPlaneSlice, MoMeshInterpolatedLogicalSlice, MoMeshIsoline, MoMeshIsosurface, MoMeshLine, MoMeshLineRepresentation, MoMeshLogicalSlice, MoMeshOutline, MoMeshPlaneSlice, MoMeshPointProbe, MoMeshRepresentation, MoMeshSkin, MoMeshSlab, MoMeshSphereSlice, MoMeshStreamline, MoMeshSurface, MoMeshSurfaceRepresentation, MoMeshVector, MoPredefinedColorMapping, MoScalarSet, MoScalarSetI, MoScalarSetIj, MoScalarSetIjk, MoStringSet, MoTessellator, MoVec3SetI, MoVec3SetIj, MoVec3SetIjk, SoRemoteVizClient, SoOrthoSliceDragger, SoFenceSlice, SoHeightFieldGeometry, SoHeightFieldProperty, SoHeightFieldPropertyMask, SoHeightFieldRender, SoObliqueSlice, SoOffscreenVolumeRender, SoOrthoSlice, SoSlice, SoUniformGridClipping, SoUniformGridProjectionClipping, SoVolumeBufferedShape, SoVolumeClippingGroup, SoVolumeData, SoVolumeDataDrawStyle, SoVolumeFaceSet, SoVolumeGroup, SoVolumeIndexedFaceSet, SoVolumeIndexedTriangleStripSet, SoVolumeIsosurface, SoVolumeMask, SoVolumeMaskGroup, SoVolumeRender, SoVolumeRenderingPhysicalQuality, SoVolumeRenderingQuality, SoVolumeShader, SoVolumeShape, SoVolumeSkin, SoVolumeTransform, SoVolumeTriangleStripSet, MedicalCPUDataCompositor, SoOffscreenVolumeRenderCustom, and SoTransferFunction2D.
| SbBool SoNode::isOverride | ( | ) | const [inline, virtual] |
Returns the state of the override flag.
Reimplemented in SoBaseColor, SoColorIndex, SoComplexity, SoDepthBuffer, SoDrawStyle, SoEnvironment, SoFont, SoFullSceneAntialiasing, SoLightModel, SoMaterial, SoMaterialBinding, SoPackedColor, SoPattern, SoPickStyle, SoPolygonOffset, SoShapeHints, SoTextProperty, SoTexture, and SoVertexProperty.
| void SoNode::setOverride | ( | const SbBool | state | ) | [inline, virtual] |
Turns the override flag on or off.
The following property nodes are affected by the override flag: SoBaseColor, SoColorIndex, SoComplexity, SoDepthBuffer, SoDrawStyle, SoEnvironment, SoFont, SoFullSceneAntialiasing, SoLightModel, SoMaterial, SoMaterialBinding, SoPackedColor, SoPattern, SoPickStyle, SoPolygonOffset, SoShapeHints, SoVertexProperty, SoTextProperty.
Every node has an override flag associated with it. The override flag is a powerful mechanism typically used (sparingly) near the top of a scene graph. When this flag is set, any nodes of the same type encountered later in the graph are ignored even if they also have their own override flag set. For example, you might insert a line-style SoDrawStyle node at the top of a graph to ensure that the whole scene is drawn as wireframe objects, regardless of drawing styles specified lower in the scene graph. Use the setOverride() method to set and reset the override flag. The isOverride() method returns the state of the override flag.
Normally, the override flag is not used within a scene graph for modeling. Use it in applications where you need to specify a temporary change to the whole graph.
Note: The override flag is not written to a file.
Setting the override flag on a node whose field values are not inherited (for example on a sphere with a radius of 7) has no effect on other nodes in the graph of that type.
Reimplemented in SoBaseColor, SoColorIndex, SoComplexity, SoDepthBuffer, SoDrawStyle, SoEnvironment, SoFont, SoFullSceneAntialiasing, SoLightModel, SoMaterial, SoMaterialBinding, SoPackedColor, SoPattern, SoPickStyle, SoPolygonOffset, SoShapeHints, SoTextProperty, SoTexture, and SoVertexProperty.
| virtual void SoNode::touch | ( | ) | [virtual] |
Marks an instance as modified, simulating a change to it.
This will notify auditors (parent nodes, connected engines, and so on) of a change to this object and cause attached sensors to be triggered.
Reimplemented from SoBase.
Friends And Related Function Documentation
friend class inventor::impl::SoCachedGroupImpl [friend] |
friend class inventor::node::SoConstNode [friend] |
friend class SoAction [friend] |
friend class SoCacheElement [friend] |
friend class SoChildList [friend] |
friend class SoLdmValuationAction [friend] |
Reimplemented in SoDataSet, and SoLdmShape.
friend class SoLightPath [friend] |
friend class SoPath [friend] |
friend class SoTraversalPassImpl [friend] |
friend class StringConcatCallback [friend] |
The documentation for this class was generated from the following file:
- Inventor/nodes/SoNode.h
