MiVolumeMeshUnstructured Class Reference
[Mesh interfaces]
Unstructured volume mesh abstract interface.
More...
#include <MeshVizXLM/mesh/MiVolumeMeshUnstructured.h>
Public Member Functions | |
| virtual const MiVolumeTopologyExplicitI & | getTopology () const =0 |
| virtual const MiVolumeMeshUnstructured * | getNewClone () const |
Protected Member Functions | |
| virtual std::ostream & | toStream (std::ostream &s) const |
Detailed Description
Unstructured volume mesh abstract interface.
This interface defines an unstructured volume mesh. It can contain any type of volume cell, like tetrahedrons, hexahedrons etc.
SEE ALSO
MiVolumeMeshCurvilinear, MiVolumeMeshHexahedronIJK, MiVolumeMeshRectilinear, MiVolumeMeshRegular, MiVolumeMeshUnstructuredIJK, MiVolumeMeshVertexHexahedronIjk
- See related examples:
Member Function Documentation
| virtual const MiVolumeMeshUnstructured* MiVolumeMeshUnstructured::getNewClone | ( | ) | const [inline, virtual] |
Gets a new clone of this mesh.
This method creates and returns a new instance of the class of this object by copying all fields of this instance. The application is responsible for deleting the new instance returned. This method is not pure virtual because it is not always necessary to get a copy of a mesh. However the mesh instances returned by any extraction method are always cloneable. By default this method throws an exception of type MiAbstractMethodError.
Reimplemented in MeXVolumeMeshUnstructured.
| virtual const MiVolumeTopologyExplicitI& MiVolumeMeshUnstructured::getTopology | ( | ) | const [pure virtual] |
Returns the topology of this mesh.
Implements MiMeshUnstructuredI.
Implemented in MeXVolumeMeshUnstructured, MbVolumeMeshHexahedron< _CoordT, _ScalarT, _Vec3T >, MbVolumeMeshPolyhedron< _CoordT, _ScalarT, _Vec3T >, MbVolumeMeshTetrahedron< _CoordT, _ScalarT, _Vec3T >, and MyVolumeMeshUnstructured.
| virtual std::ostream& MiVolumeMeshUnstructured::toStream | ( | std::ostream & | s | ) | const [inline, protected, virtual] |
Performs an output operation on a stream which is returned afterward. This method is protected since only called by the output operator <<. This method is not pure virtual and output by default the geometry and topology of a mesh. Whenever a different output is needed, this method can be implemented in the subclass to get a different output format. No std::ostream& operator << needs to be defined in any subclass. This allows you to benefit from the virtual inheritance when using the output operator on an abstract class.
Implements MiMesh.
The documentation for this class was generated from the following file:
- MeshVizXLM/mesh/MiVolumeMeshUnstructured.h
