MiLineMeshUnstructured Class Reference
[Mesh interfaces]
Unstructured Line mesh abstract interface.
More...
#include <MeshVizXLM/mesh/MiLineMeshUnstructured.h>
Public Member Functions | |
| virtual const MiLineTopologyExplicitI & | getTopology () const =0 |
Protected Member Functions | |
| virtual std::ostream & | toStream (std::ostream &s) const |
Detailed Description
Unstructured Line mesh abstract interface.
This interface defines an unstructured line mesh. This is a list of MiLineCell segments.
SEE ALSO
MiLineMeshCurvilinear, MiLineMeshRegular
- See related examples:
Member Function Documentation
| virtual const MiLineTopologyExplicitI& MiLineMeshUnstructured::getTopology | ( | ) | const [pure virtual] |
Returns the topology of this mesh.
Implements MiMeshUnstructuredI.
Implemented in MeXLineMeshUnstructured, MbLineMeshUnstructured< _CoordT, _ScalarT, _Vec3T >, and MyLineMeshUnstructured.
| virtual std::ostream& MiLineMeshUnstructured::toStream | ( | std::ostream & | s | ) | const [inline, protected, virtual] |
Performs an output operation on a stream which is returned afterward. This method is protected since only called by the output operator <<. This method is not pure virtual and output by default the geometry and topology of a mesh. Whenever a different output is needed, this method can be implemented in the subclass to get a different output format. No std::ostream& operator << needs to be defined in any subclass. This allows you to benefit from the virtual inheritance when using the output operator on an abstract class.
Implements MiMesh.
The documentation for this class was generated from the following file:
- MeshVizXLM/mesh/MiLineMeshUnstructured.h
